Key Features & Specifications:

The Neway swing check valve incorporates optimized disc design, renewable seal-welded seats with Stellite overlay, and robust hinge mechanism to ensure reliable operation under high-pressure conditions. Our valves undergo rigorous quality checks at every stage of production, from material selection to final assembly, guaranteeing leak-free performance and compliance with international standards.

• Size Range: NPS 2″ to 60″ (DN50 to DN1500)
• Pressure Rating: ASME CLASS 150 to 2500 (PN16 to PN420)
• Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Low-Temperature Steel
• Design Standards: BS 1868, ASME B16.34, API 594
• End Connections: Raised Face (RF), Butt Weld (BW), Ring Type Joint (RTJ)
• Installation: Horizontal or vertical (flow bottom to top)
• Applications: Oil & Gas Production, Refining, Petrochemical, Power Generation, Water Treatment
• Special Features: Bolted Cover Design, Swing Disc Type, Seal Welded Seat, Optional Damping Device
