Key Features & Specifications:

Neway cryogenic gate valves undergo rigorous cryogenic testing to guarantee performance in extreme conditions. They feature extended bonnet designs, low-emission packing per ISO 15848, anti-static and fire-safe capabilities, as well as cavity relief mechanisms to prevent overpressure. Constructed from low-temperature materials such as CF8, CF8M, and CF3, Neway cryogenic valves offer both durability and safety in demanding environments.

• Temperature Range: -196°C to +80°C (lower temperatures available)
• Size Range: NPS 1/2″ to 52″ (DN15 to DN1300)
• Pressure Rating: ASME CLASS 150 to 2500 (PN16 to PN420)
• Body Material: Stainless Steel (CF8, CF8M, CF3, CF3M), Forged Materials
• Trim Materials: Low-Temperature Stainless Steel, Special Alloys
• Design Standards: BS6364, Shell SPE 77/200, API 603, ASME B16.34
• End Connections: Raised Face (RF), Butt-Weld (BW), Ring-Type Joint (RTJ)
• Operation: Manual, Pneumatic, Electric, Hydraulic
• Special Features: Extended Bonnet, Fire-Safe Design, Low Emission Packing, Anti-Static Device
