Key Features & Specifications:

The Neway fully welded trunnion ball valve is designed for zero leakage and maximum durability in critical service. It incorporates advanced engineering features such as anti-blowout stems, secondary metal-sealing in fire-safe conditions, and low-emission packing options to meet the most stringent environmental and safety standards.

• Size Range: NPS 2″ to 60″ (DN50 to DN1500)
• Pressure Rating: ASME CLASS 150 to 1500 (PN16 to PN250)
• Temperature Range: -46°C to 200°C
• Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel
• Design & Test Standards: API 6D, API 607, API 6FA, ASME B16.34
• Sealing Capability: Bidirectional, Double Block & Bleed (DBB)
• End Connections: Butt-Weld (BW), Flanged (FLNG)
• Operation: Manual, Pneumatic, Electric, Electro-hydraulic

Special Options: Stem Extensions (for buried service), Custom Transition Pieces
